Description
The Blustream OPT41AU is an advanced 4-way optical audio switch. Perfect for the integration of multiple audio sources with a soundbar. The OPT41AU also has a built in DAC and simultaneous digital and analogue stereo audio outputs. The OPT41AU supports 192kHz sample rates and up to 24-bit resolution for enhanced sound reproduction.
Box Contents
1 x OPT41AU
1 x IR Remote Control
1 x 5V/1A DC Power Supply
1 x Mounting Kit
1 x User Manual
Key Features
-
Features 4 x optical SPDIF digital inputs which can be switched to single optical output
-
DAC (Digital to Analogue Audio Converter) converts selected optical digital to analogue left / right stereo audio output
-
Built-in digital audio converter converts selected optical audio input to coaxial digital output
-
Outputs optical digital, coaxial digital and analogue left / right stereo audio concurrently
-
Supports sample rates 32kHz, 44.1kHz, 48kHz, 96kHz & 192kHz up to 24-bit resolution
-
Supports LPCM, DTS, Dolby Digital and Dolby Digital plus when used as a straight digital in / digital out switcher
-
Ultra low jitter and high fidelity design
-
Input selection button on front panel to toggle between optical inputs
-
IR receiver on front panel to switch inputs and turn on / off audio outputs using supplied IR remote
-
External IR input can be used to extend IR with Blustream IR receiver cable
Specifications
-
Audio Input Connectors: 4 x Optical (SPDIF)
-
Output Connectors: 1 x Optical (SPDIF), 1 x RCA (SPDIF) & 1 x Analogue audio L/R (3.5mm stereo jack)
-
IR Input Ports: 1 x 3.5mm stereo jack
-
Product Dimensions (W x D x H): 140 x 80 x 25mm (with connections)
-
Product Dimensions (W x D x H): 140 x 70 x 25mm (without connections)
-
Product Weight: 0.25kg (excluding accessories)
-
Carton/Box Dimensions (W x D x H): 210 x 125 x 90mm
-
Shipping Weight: 0.5kg
-
Operating Temperature: 32°F to 104°F (0°C to 40°C)
-
Storage Temperature: -4°F to 140°F (-20°C to 60°C)
-
Power Supply: 5V/1A DC, screw type connector
-
Mounting kit included
